SKU: SKU: NSKYBP285MR
Profile: BP285M
Application: Ultimate Road.
Unit Type: Re-Profiled Camshaft.
Note:Designed for use in engines which utilise mechanical followers.
Note:These are re-profile camshafts only. You will need to complete our Send Parts form and send us your existing camshafts. For more information, please take a look at our Reprofiling page.
Note: Re-Profiled camshafts may vary from specifications listed.
| Weight | 3 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2300-7600 |
| Power Increase | 30BHP+ |
| Duration Inlet | 264° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .344" 8.73mm |
| Valve Exhaust Lift | .342" 8.68mm |
| Timing Inlet | 24 - 60 |
| Timing Exhaust | 60 - 24 |
| Full Inlet Lift | 108° |
| Full Exhaust Lift | 108° |
| TDC Inlet Lift | .058" 1.48mm |
| TDC Exhaust Lift | .056" 1.43mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
