SKU: SKU: METBP270MPI
Profile: BP270MPI
Application: Fast Road.
Unit Type Blank.
Multipoint Injection cam. Excellent torque and very good idle.
Download:-
Right click link and select 'Save link as' to download.
Click link to open in a new tab.
Please check the end float of the camshaft when using non O.E replacement oil pump, as additional machining may be required to the pump.
| Weight | 2 kg |
|---|---|
| Application | Fast Road |
| Power Band | 1500-6500 |
| Power Increase | 10BHP |
| Duration Inlet | 252° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .357" 9.07mm |
| Valve Exhaust Lift | .348" 8.84mm |
| Timing Inlet | 16 - 56 |
| Timing Exhaust | 57 - 27 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 105° |
| TDC Inlet Lift | .039" 0.98mm |
| TDC Exhaust Lift | .059" 1.51mm |
| Valve Inlet Clearance | .012" .30mm |
| Valve Exhaust Clearance | .016" .40mm |
