SKU: SKU: METBP270B
Profile: BP270.
Application: Fast Road.
Unit Type. Blank.
Designed for Carburettor use in all engine sizes. Smooth idle. No machining required.
Piper 'HR' profiles are available by request. Please Contact Us for details.
Blank camshafts are only available as A+ Series (Metro slot type oil pump drive) and have drilled lobes for additional lubrication.
Download:-
Right click link and select 'Save link as' to download.
Click link to open in a new tab.
Please check the end float of the camshaft when using non O.E replacement oil pump, as additional machining may be required to the pump.
| Weight | 2 kg |
|---|---|
| Application | Fast Road |
| Power Band | 1500-6500 |
| Power Increase | 10BHP |
| Duration Inlet | 276° |
| Duration Exhaust | 276° |
| Valve Inlet Lift | .385" 9.78mm |
| Valve Exhaust Lift | .385" 9.78mm |
| Timing Inlet | 31 - 65 |
| Timing Exhaust | 65 - 31 |
| Full Inlet Lift | 107° |
| Full Exhaust Lift | 107° |
| TDC Inlet Lift | .082" 2.08mm |
| TDC Exhaust Lift | .080" 2.03mm |
| Valve Inlet Clearance | .012" .30mm |
| Valve Exhaust Clearance | .012" .30mm |
