SKU: SKU: METBP255B
Profile: BP255
Application: Mild Road / Turbo.
Unit Type: Blank.
Note: The original Piper 'HR' profiles are still available. Please Contact Us for details.
Blank camshafts are only available as A+ Series (Metro slot type oil pump drive) and have drilled lobes for additional lubrication.
Download:-
Right click link and select 'Save link as' to download.
Click link to open in a new tab.
Please check the end float of the camshaft when using non O.E replacement oil pump, as additional machining may be required to the pump.
| Weight | 2 kg |
|---|---|
| Application | Mild Road |
| Power Band | 1000-6000 |
| Power Increase | 8BHP |
| Duration Inlet | 264° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .360" 9.14mm |
| Valve Exhaust Lift | .360" 9.14mm |
| Timing Inlet | 24 - 60 |
| Timing Exhaust | 60 - 24 |
| Full Inlet Lift | 108° |
| Full Exhaust Lift | 108° |
| TDC Inlet Lift | .042" 1.07mm |
| TDC Exhaust Lift | .042" 1.07mm |
| Valve Inlet Clearance | .012" .30mm |
| Valve Exhaust Clearance | .012" .30mm |
