SKU: SKU: LOTBP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note: Available with or without oil groove in the front journal.
Note: To use non groove type, additional machining to the camshaft caps is required.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2000-7000 |
| Power Increase | 16BHP |
| Duration Inlet | 280° |
| Duration Exhaust | 280° |
| Valve Inlet Lift | .384" 9.75mm |
| Valve Exhaust Lift | .382" 9.70mm |
| Timing Inlet | 30 - 70 |
| Timing Exhaust | 70 - 30 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .090" 2.28mm |
| TDC Exhaust Lift | .088" 2.23mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
