SKU: SKU: FECO23BP255B
Profile: BP255.
Application: Mild Road.
Unit Type: Blank.
Note: Direct replacement upgrade designed to work with standard O.E. springs.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Mild Road |
| Power Band | 1800-6500 |
| Duration Inlet | 244° |
| Duration Exhaust | 234° |
| Valve Inlet Lift | .340" 8.64mm |
| Valve Exhaust Lift | .315" 8.01mm |
| Timing Inlet | '-7 - 71 |
| Timing Exhaust | 41 - 13 |
| Full Inlet Lift | 129° |
| Full Exhaust Lift | 104° |
| TDC Inlet Lift | .004" 0.11mm |
| TDC Exhaust Lift | .023" 0.57mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .012" .30mm |
