SKU: SKU: DUR200B
Profile: Piper 200 Spec.
Application: -
Unit Type: Blank.
Note: Suitable for use with standard O.E. valve springs. Piper VSSDUR Valve Springs & Caps recommended.
Note:Can be installed without machining pistons, though basic checks are necessary.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2000-7200 |
| Duration Inlet | 288° |
| Duration Exhaust | 277° |
| Valve Inlet Lift | .366" 9.30mm |
| Valve Exhaust Lift | .364" 9.25mm |
| Timing Inlet | 34 - 74 |
| Timing Exhaust | 68.5 - 28.5 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .034" 0.85mm |
| TDC Exhaust Lift | .031" 0.78mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
