SKU: SKU: DUR1892B
Profile: 1892.
Application: -
Unit Type: Blank.
For use with throttle bodies.
Note: Not suitable for use with standard O.E. valve springs. Piper VSSDUR Valve Spring & Cap set must be used.
Note: 1892 is the hottest profile which can be fitted without machining pistons.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2000-7200 |
| Duration Inlet | 276° |
| Duration Exhaust | 276° |
| Valve Inlet Lift | .402" 10.21mm |
| Valve Exhaust Lift | .400" 10.16mm |
| Timing Inlet | 30 - 66 |
| Timing Exhaust | 66 - 30 |
| Full Inlet Lift | 108° |
| Full Exhaust Lift | 108° |
| TDC Inlet Lift | .084" 2.13mm |
| TDC Exhaust Lift | .082" 2.08mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
