SKU: SKU: COSBP320HTB
Profile: BP320HT.
Application: Race Turbo.
Unit Type: Blank.
Designed for Turbo engines utilising Hydraulic followers.
Note:When fitting to a 2WD head, Piper COSWASH thrust spacers are required.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new browser.
| Weight | 6 kg |
|---|---|
| Application | Race |
| Power Band | 3500-7500 |
| Duration Inlet | 264° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .428" 10.87mm |
| Valve Exhaust Lift | .428" 10.87mm |
| Timing Inlet | 26 - 58 |
| Timing Exhaust | 58 - 26 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .078" 1.98mm |
| TDC Exhaust Lift | .078" 1.98mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
