SKU: SKU: COSBP285HTB
Profile: BP285HT.
Application: Ultimate Road Turbo.
Unit Type: Blank.
Designed for Turbo engines utilising Hydraulic followers.
Note:When fitting to a 2WD head, Piper COSWASH thrust spacers are required.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new browser.
| Weight | 6 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2500-6600 |
| Duration Inlet | 264° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .350" 8.89mm |
| Valve Exhaust Lift | .340" 8.64mm |
| Timing Inlet | 22 - 62 |
| Timing Exhaust | 62 - 22 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .047" 1.19mm |
| TDC Exhaust Lift | .047" 1.19mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
