SKU: SKU: A16VBP270HTB-SHORT
Profile: BP270HT.
Application: Fast Road Turbo.
Unit Type: Blank.
Designed for Turbo engines utilising Hydraulic followers.
Note: If you require the Exhaust camshaft to be ground on an Inlet blank, please choose 'YES' on the drop down box.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Fast Road |
| Power Band | 1800-6500 |
| Power Increase | 15BHP |
| Duration Inlet | 256° |
| Duration Exhaust | 256° |
| Valve Inlet Lift | .372" 9.45mm |
| Valve Exhaust Lift | .372" 9.45mm |
| Timing Inlet | 18 - 58 |
| Timing Exhaust | 58 - 18 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .032" 0.81mm |
| TDC Exhaust Lift | .032" 0.81mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
| SHORT EXHAUST CAMSHAFT REQUIRED | YES, NO |
