SKU: SKU: EDE22739
Edelbrock Ignition Coil #22739 is a universal 12-volt cannister-style coil designed as a high-quality direct bolt-on replacement for OEM ignition coils. This advanced coil has a primary resistance of 1.4 ohms with an output of 42,000 volts. Internally, each Edelbrock Coil features heavy-duty primary and secondary windings for higher energy and greater spark that can help to provide quicker starts with improved idle quality. With a durable oil-filled housing, Edelbrock Coils are resistant to heat, shock and vibration with an effective operating range of 0 to 6,500 RPM.
| Terminal Type | Socket |
| Terminal Quantity | 1 |
| Mounting Bracket Included | No |
| Voltage | 12V 2H |
| Coil Wire Included | No |
| Oil Filled | Yes |
| Mount Type | Plug |
| Ratio | 94:1 Turns |
| Coil Shape | Round |
| Mounting Position | Cylinder Head |
| Maximum Voltage | 42000 |
| Mounting Hardware Included | No |
| Requires External Resistor | No |
| 7642 | 6500 R3 |
| Material | Steel |
| Connector Gender | Male |
| Terminal Gender | Female |
| Quantity | Sold Individually |
| Ignition Type | Distributorless |
| Primary Resistance | 1.4 82 |
| Coil Type | Canister |
| Secondary Resistance | 9.2 B49 |
