HKS LEGAMAX Premium GRB EJ20 Turbo (Main) - 31021-AF013

LEGAMAX Premium

Vehicle: IMPREZA WRX STI

Application

• Model/Chassis: GRF
• Engine: EJ25(TURBO)
• Model Year: 09/02 - 14/08
• Code No.: 31021-AF013

Specifications

IMPREZA WRX STI CBA-GRF Cert. No. JQR10091077 Vehicle IMPREZA WRX STI Model GRF Engine EJ25(TURBO) Model Year 09/02 - 14/08 Shape of muffler RM (Titan) (LEGAMAX Premium) Main material S304 Diameter of tip 90 x 2 L&R Diameter of center pipe 65 (*1) Close noise level Stock L81 R81 HKS L82 R83 About road clearance(*2) Clearance 230mm Portion of the kit Main silencer Remarks Product Weight Remarks Main pipe only. About HKS muffler *1: About center pipe Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension. *2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle. The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit. Caution: Hook, bracket, stay may be changed without prior notice. ★ Exhaust noise level at idle. [ CLOSE ]

Source: HKS Japan · Detail page
