HKS 23+ GR Corolla HIPERMAX R GZEA14H FULL KIT - 80310-AT007

Application

• Engine: G16E-GTS
• Code No.: 80310-AT007

Specifications

GR COROLLA GZEA14H The joy of controlling it as you wish, and its versatility to adapt from the circuit to winding roads "Ultimate Multi-Performer" with refined driving comfort Introduction of HIPREMAX R , designed for circuit driving with high-grip tires. Features front camber adjustment mechanism adjustable up to approximately 4 degrees. Convenient camber adjustment accessible from the tire house side despite the deep position of the upper part in the engine compartment. Rear damping force adjustment achievable without removing shock absorbers. Testing conducted with YOKOHAMA ADVAN A052 (265/35R18) tires. Recommended damping dial settings for Fuji Speedway: 10 clicks for the front, 13 clicks for the rear. Adjustment tip: To avoid understeer, adjust the rear towards toe-out direction for improved agility. Versatile performance: Suitable for both track driving and street use. Application Engine G16E-GTS Model Year 22/12 - Remarks Confirmed in RZ grade, Morizo edition not confirmed. Specification FRONT REAR Damping force adjustment 30 steps 30 steps Base valve - - Height adjustable lower bracket 〇 〇 Upper mount Spherical bearing Spherical bearing Inverted/Normal type Inverted Normal Damper/Spring layout Coilover Separated Spring rate change at factory Possible Possible Damping force adjustment with wire - - Helper spring (Spring rate N/mm) 〇 (19.8) 〇 (19.8) Ride Height mm Factory *2 Test data Adjustable range

Source: HKS Japan · Detail page
