SKU: SKU: HKS80310-AH003
Application
Specifications
CIVIC TYPE R FK8 The fun to drive at will and the balance can be adapted from circuit to winding road. Reised Driving-Comfort, "Ultimate All-Rounder" Application Engine K20C Model Year 17/09 - 22/08 Remarks Remark: This kit is for CIVIC TYPE R, which is not able to adopt on other grades of CIVIC. *Error is displayed when the stock dampers are removed. An optional canceller is required to avoid the error display. Specification FRONT REAR Damping force adjustment 30 steps 30 steps Base valve - - Height adjustable lower bracket × 〇 Upper mount Spherical bearing Spherical bearing Inverted/Normal type Inverted Normal Damper/Spring layout Coilover Separated Spring rate change at factory Possible Possible Damping force adjustment with wire - 〇 Helper spring (Spring rate N/mm) 〇 (19.8) 〇 (19.8) Ride Height mm Factory *2 Test data Adjustable range High - Low *3 Drivable range High - Low *4 FRONT Ride height *1 649 ← 660 ～ 633 660 ～ 639 Against stock -23 ← -11 ～ -39 -11 ～ -33 REAR Ride height *1 650 ← 675 ～ 626 675 ～ 626 Against stock -28 ← -3 ～ -52 -3 ～ -52 *1. Height from road surface to fender arch. *2. Height at factory is the data tested at HKS with the setting of Full Kit. (HKS’ recommended setting.) *3. Adjustable range (However, the lowest value may not be road legal. Even within the adjustable range, car body, arm etc. may contact. In such case, it will be hard to drive. Damper oil leakage o
Source: HKS Japan · Detail page
