SKU: SKU: HKS32016-BT002
HKS Hi-Power Single Racing Version FR-S
| Cert. No. |
|---|
| Vehicle | 86 |
|---|---|
| Model | ZN6 |
| Engine | FA20 |
| Model Year | 12/04 - 21/10 |
| Shape of muffler | HP (Titan) (Hi-Power) | |
|---|---|---|
| Main material | S409 | |
| Diameter of tip | 97 | |
| Diameter of center pipe | 75 (*1) | |
| Close noise level | Stock | - |
| HKS | 104 | |
| About road clearance(*2) | Clearance | 124mm |
| Portion of the kit | 2nd center pipe | |
| Remarks | ||
| Product Weight | 11.0kg | |
・Titanium tail can slide (20mm) ・Compatible with inner silencer 3306-RA072 Note; Closed sound level under US measurement method is 95dB.
*1: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.
*2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.
Caution: Hook, bracket, stay may be changed without prior notice.
★ Exhaust noise level at idle.
Hi-Power
Vehicle: BRZ
Application
Specifications
BRZ ZC6 Cert. No. Vehicle BRZ Model ZC6 Engine FA20 Model Year 12/03 - 21/07 Shape of muffler HP (Titan) (Hi-Power) Main material S409 Diameter of tip 97 Diameter of center pipe 75 (*1) Close noise level Stock - HKS 104 About road clearance(*2) Clearance 124mm Portion of the kit 2nd center pipe Remarks Product Weight 11.0kg Remarks ・Titanium tail can slide (20mm) ・Compatible with inner silencer 3306-RA072 Note; Closed sound level under US measurement method is 95dB. About HKS muffler *1: About center pipe Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension. *2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle. The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit. Caution: Hook, bracket, stay may be changed without prior notice. ★ Exhaust noise level at idle. [ CLOSE ]
