Over 500HP with Z33!!
This kit can achieve over 500hp if the engine is strengthened, and better torque and power than GTS7040 kit with a stock engine.
【Features】
- The intercooler size is doubled compared to the existing kit. The capacity is doubled as well to withstand 500hp.
- The diameter of the suction pipe and intercooler pipe is enlarged by 35%.
- The airflow capacity of the supercharger is increased by 30% compared to the existing kit (GT7040).
- With adequate airflow, the torque & power increase are noticeable from the low to high speed range!!
【Note in order to install this kit】
- S/C Pulley: Prepare φ100 or φ110 supercharger pulley depending on the target output.
- Belt: Prepare a belt matches with the supercharger pulley.
| S/C Pulley Dia. |
Code No. |
Belt |
Code No. |
| φ100 |
12999-AK005 |
7PK1070 |
24996-AK038 |
| φ110 |
12999-AK006 |
7PK1092 |
24996-AK039 |
- Prepare a engine management system such as HKS F-CON.
- Select the spark plug which heat range is appropriate to the vehicle specifications.
- Fuel Parts: HKS Fuel Upgrade Kit which is designed to withstand 400hp or more.
