Name: Ford Racing - Tremec Tkx-600 5 Speed Transmission .81 Overdrive - M-7003-TKX81
Brand: Ford Racing
SKU: FRPM-7003-TKX81
Price: 5339.06 CAD
Availability: InStock

Tremec Tkx-600 5 Speed Transmission .81 Overdrive — manufactured by Ford Performance Parts (Ford Motor Company).

Ford Performance is proud to offer the latest 5 speed manual transmission from Tremec - the TKX. Capable of handling 600 lb.-ft. of torque, it's the perfect 5 speed manual transmissions for your custom build.

Reduced overall size - easier to package in a variety of vehicles
Improved, smoother shifting
hybrid carbon/bronze synchronizers - 7,500 rpm shift capability
wider, more durable gears than TKO transmission
caged needle bearings for improved durability
26 spline input shaft / 31 spline output shaft
1st gear = 2.87, 2nd gear = 1.89, 3rd gear = 1.28, 4th gear = 1, 5th gear = .81
dry weight = 99 lbs.
Fluid capacity 2.7 quarts - Tremec HIgh Performance Manual transmission fluid or Mobit 1 Synthetic ATF recommended
Use M-6392-R58 bellhousing for 302/351 engines
Use M-6392-M46 bellhousing for 4.6/5.0/5.2/5.4 modular engines

Specifications

Part Type	Driveline: Manual Trans
Warranty Availability	Available
Package Dimensions	17" x 14" x 35"
Package Weight	108.5 lb(s)
UPC Code	756122015506
Country of Origin	Mexico

Genuine Ford Racing Parts — backed by Ford Motor Company's factory engineering and warranty.
