Bilstein 23-25 Chevrolet Colorado (w/ 0-1in Rear Lift) B8 5100 Shock Absorber - Rear - 24-336529

Bilstein B8 5100 shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

Features

• 46mm monotube design ensures consistent, fade-free performance in all conditions
• Patented digressive valving instantly reacts to changing surface conditions
• Vehicle specific tuning

Specifications

• Extended Length (mm): 612.0
• Upper Mount Type: Eye 14.1mm
• Finish: Zinc Plated
• Internal Design: Monotube
• Collapsed Length (in): 15.24
• Reservoir: No
• Series: B8 5100
• Lower Mount Type: Eye 14.1mm
• Collapsed Length (mm): 387.3
• Body Design: Smooth Body (Non-Coilover)
• Boot Included: Black Bellows
• Extended Length (in): 24.09
• Adjustable Damping: Non-Adjustable
• Spring Seat Included: No
• Piston Diameter: 46mm
• Shaft Diameter: 14mm
• Stroke/Travel Length (mm): 224.8
• Stroke/Travel Length (in): 8.85

Application

• Chevrolet Colorado 2023-2026
